DRV8880EVM, Evaluation Module for DRV8880 Dual H-Bridge Stepper Motor Driver
Progetto di riferimento usando la parte DRV8880PWPR di Texas Instruments
Immagine
1 / 4
Documenti associati
Per prodotti finali
- Factory Automation
- Printers
- Robotics
- Scanners
- Security Camera
Per contattare il Servizio Clienti.
- DRV8880EVM, Evaluation Module is a platform revolving around the DRV8880 medium voltage dual H-bridge driver and highly-configurable power stage. This device has been optimized to drive a single bipolar stepper with up to 16 degrees of internally generated Micro-Stepping. The EVM houses an MSP430 microcontroller and an USB interface chip. The USB chip allows for serial communications from a PC where a Windows application is used to schedule serial commands. These commands can be used to control each of the device's signals and drive the stepper motor by issuing the step commands at the desired rate
Funzioni principali
-
Motor TypeStepper Motor
Parti in primo piano (2)
| Numero parte | Produttore | Tipo | Per contattare il Servizio Clienti. | |||
|---|---|---|---|---|---|---|
|
MSP430F2617TPM | Texas Instruments | Microcontrollers - MCUs | MCU 16-bit MSP430 RISC 92KB Flash 2.5V/3.3V 64-Pin LQFP Tray | ACQUISTA | |
|
DRV8880PWPR | Texas Instruments | Motor Controller and Driver ICs | Dual H-Bridge Motor Driver 28-Pin HTSSOP EP T/R | ACQUISTA | |
