TIDEP0034, 66AK2L06 Reference Design JESD Attach to Wideband ADCs and DACs
Using Part
Vignette
1 / 14
Pour les produits finaux
- Missile Defense
- Radar System
- Test and Measurement
Description
- TIDEP0034, 66AK2L06 Reference Design JESD Attach to Wideband ADCs and DACs. for developers currently using an FPGA or ASIC to connect to high speed data converters who need faster time to market with increased performance and significant reduction in cost, power and size this reference design includes the first widely available processor integrating JESD204B interface and Digital Front End (DFE) processing. Connecting the 12J4000 ADC and 38J84 DAC provides an efficient solution for Test/Measurement and Defense applications
Caractéristiques principales
-
Embedded System TypeDSP
-
Core ProcessorARM Cortex-A15
-
PlatformIndustrial Development
Pièces en vedette (6)
| Pièce numéro | Fabricant | Type | Description | |||
|---|---|---|---|---|---|---|
|
ADC12J4000NKE | Texas Instruments | Analog to Digital Converters - ADCs | 1-Channel Single ADC Folding/Interpolating 4Gsps 12-bit JESD204B 68-Pin VQFN EP Tray | Ajouter au panier | |
|
DAC38J84IAAV | Texas Instruments | Digital to Analog Converters - DACs | DAC 4-CH Segment 16-bit 144-Pin FCBGA Tray | Ajouter au panier | |
|
|
DAC38J84IAAVR | Texas Instruments | Digital to Analog Converters - DACs | DAC 4-CH Segment 16-bit 144-Pin FCBGA T/R | Ajouter au panier | |
|
LMK04828BISQ/NOPB | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 0.001MHz to 750MHz-IN 3100MHz-OUT 64-Pin WQFN EP T/R | Ajouter au panier | |
|
|
LMK04828BISQ/NOPB | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 0.001MHz to 750MHz-IN 3100MHz-OUT 64-Pin WQFN EP T/R | Ajouter au panier | |
|
66AK2L06XCMS | Texas Instruments | Digital Signal Processors - DSPs | DSP Fixed-Point/Floating-Point 1.2GHz Medical 900-Pin FCBGA Tray | Ajouter au panier | |
