DC2157A, Demo Board Using for LTM4630EY-1 Dual 18A/Single 36A Buck module Regulator, 4.5V = VIN = 15V, Vout1 = 1.5V @ 18A, Vout2 = 1V @ 18A
Using Part
Vignette
1 / 3
Documents connexes
Pour les produits finaux
- Power Supplies
Description
- DC2157A, Demo Board Using for LTM4630EY-1 Dual 18A/Single 36A Buck module Regulator, 4.5V = VIN = 15V, Vout1 = 1.5V @ 18A, Vout2 = 1V @ 18A. The Demonstration Circuit 2157A features the LTM4630EY-1 high efficiency, high density, dual 18A, switch mode step-down power module regulator with ±0.8% total DC output accuracy. The input voltage is from 4.5V to 15V. The output voltage is programmable from 0.6V to 1.8V. DC2157A can deliver up to 18A maximum in each channel
Caractéristiques principales
-
Conversion TypeDC to DC
-
Input Voltage4.5 to 15 V
-
Output Voltage1|1.5 V
-
Output Current18 A
-
Efficiency89.7 %
-
TopologyBuck
Pièces en vedette (2)
| Pièce numéro | Fabricant | Type | Description | |||
|---|---|---|---|---|---|---|
|
LTM4630EY-1B#PBF | Analog Devices | DC to DC Converter and Switching Regulator Module | Module DC-DC 2-OUT 0.6V to 1.8V 18A 144-Pin BGA Tray | Ajouter au panier | |
|
LTM4630EY-1A#PBF | Analog Devices | DC to DC Converter and Switching Regulator Module | Module DC-DC 2-OUT 0.6V to 1.8V 18A/18A 144-Pin BGA Tray | Ajouter au panier | |
