Typical Application for LTC4212 Hot-Swap Controller with Power-Up Time-out
使用 Analog Devices 的 LTC4212 的参考设计
1 / 1
依据最终产品
- Circuit Breaker
- Hot-Swap Board Insertion
说明
- Typical Application for LTC4212 is a Hot-Swap controller that allows a board to be safely inserted and removed from a live backplane. An internal high side switch driver controls the gate of an external N-channel MOSFET for supply voltages ranging from 2.5V to 16.5V
主要特色
-
Input Voltage2.5 to 16.5 V
-
Output Voltage2.5|3.3|5 V
-
Output Current1.5 A
Featured Parts (6)
| 零件编号 | 供应商 | 类别 | 说明 | |||
|---|---|---|---|---|---|---|
|
LTC4212CMS#PBF | Analog Devices | Hot Swap Controllers | Hot Swap Controller 1-CH 16.5V N-Channel Positive Low Voltage 10-Pin MSOP Tube | 买入 | |
|
|
LTC4212IMS#PBF | Analog Devices | Hot Swap Controllers | Hot Swap Controller 1-CH 16.5V N-Channel Positive Low Voltage 10-Pin MSOP Tube | 买入 | |
|
|
LTC4212IMS#TR | Analog Devices | Hot Swap Controllers | Hot Swap Controller 1-CH 16.5V N-Channel Positive Low Voltage 10-Pin MSOP T/R | 买入 | |
|
|
LTC4212IMS | Analog Devices | Hot Swap Controllers | Hot Swap Controller 1-CH 16.5V N-Channel Positive Low Voltage 10-Pin MSOP | 买入 | |
|
|
LTC4212CMS#TRPBF | Analog Devices | Hot Swap Controllers | Hot Swap Controller 1-CH 16.5V N-Channel Positive Low Voltage 10-Pin MSOP T/R | 买入 | |
|
|
LTC4212IMS#TRPBF | Analog Devices | Hot Swap Controllers | Hot Swap Controller 1-CH 16.5V N-Channel Positive Low Voltage 10-Pin MSOP T/R | 买入 | |
