DC538A, LTC3734EUH Demo Board, Single Phase IMVP4 Power Supply, Vin=7.5V to 24V, Vout= 0.6V-1.75V@15A
Using Part
Vignette
1 / 8
Documents connexes
Pour les produits finaux
- Desktops and Servers
Description
- DC538A, Demonstration Board is an IMVP4 power supply for powering Intel mobile Banias CPUs(LV and ULV types). The input voltage is 7.5V to 20V, the output voltage is programmed by the 6-bit VID inputs as well as the mode signals (DPRSLPVR, STPCPU, PSI)
Caractéristiques principales
-
Conversion TypeDC to DC
-
Input Voltage7.5 to 21 V
-
Output Current12 A
-
Efficiency92 %
-
TopologyBuck
