taoglasPCS.06.AAntenne
Antenna Dielectric -5.64dB Gain 698MHz/806MHz/960MHz/2200MHz/2690MHz T/R
Havok PCS.06 4G/3G Low Profile SMD Antenna
The Havok PCS.06.A is a compact, low-profile SMD LTE/cellular 4G/3G/2G embedded antenna designed for direct SMD mounting on a device PCB. It delivers high efficiency in a size of 42x10x3mm. Additionally, the PCS.06.M Mirrored version is available for use in MIMO systems.
Key Features and Benefits:
- • Low Profile LTE/Cellular 4G/3G/2G SMD Dielectric Antenna
- • GSM/CDMA/DCS/PCS/WCDMA/UMTS/HSDPA /GPRS/EDGE
- • 698-960MHz, 1710-2690MHz
- • High-Efficiency Multi-Band SMD Antenna
- • Dimensions: 42*10*3mm
- • CE Certified
Applications:
- • Connected health
- • Handheld devices
- • Wearables
Related Products:
| Compliant | |
| EAR99 | |
| Active | |
| 8517.71.00.00 | |
| Automotive | Unknown |
| PPAP | Unknown |
| Dielectric | |
| Omni-Directional | |
| Linear | |
| 617|698|824|1710|2300 | |
| 698|806|960|2200|2690 | |
| -5.64dB | |
| 50 | |
| 2000 | |
| -40 | |
| 85 | |
| Tape and Reel | |
| Installation | Surface Mount |
| Hauteur du paquet | 3 |
| Largeur du paquet | 10 |
| Longueur du paquet | 42 |
| EDA / CAD Models |
