Typical Application for TPS61028 Power Supply Solution for Maximum Output Power Operating From a Single Alkaline Cell
使用 Texas Instruments 的 TPS61028 的参考设计
1 / 1
依据最终产品
- Battery-Powered Applications
- Cellular Phone
- Personal Digital Assistant
- Portable Audio
- Portable Medical Devices
- WLED Flashlights
说明
- Typical Application for TPS61028 Power Supply Solution for Maximum Output Power Operating From a Single Alkaline Cell. The TPS6102x family of devices provide a power supply solution for products powered by either a one-cell, two-cell, or three-cell alkaline, NiCd or NiMH, or one-cell Li-Ion or Li-polymer battery. Output currents can go as high as 200 mA while using a single-cell alkaline battery, and discharge it down to 0.9V
主要特色
-
Conversion TypeDC to DC
Featured Parts (1)
| 零件编号 | 供应商 | 类别 | 说明 | |||
|---|---|---|---|---|---|---|
|
TPS61028DRCR | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 0.9V to 6.5V Synchronous Step Up Single-Out 1.8V to 5.5V 0.8A 10-Pin VSON EP T/R | 买入 | |
