TWR-MCF51MM-KIT, Medical Development Tower System Module for MCF51MM256 Flexis ColdFire 32-bit Microcontroller for portable medical applications
使用 NXP Semiconductors 的 MCF51MM256 的参考设计
1 / 7
相关文件
依据最终产品
- Portable Medical Instrumentation
说明
- TWR-MCF51MM-KIT, Medical Development Tower System Module for MCF51MM256 Flexis ColdFire 32-bit Microcontroller. The TWR-MCF51MM module is a development board for the MCF51MM256 Flexis ColdFire 32-bit MCUs. It is designed to aid in the evaluation and prototyping of medical applications and includes an electrocardiograph sensor (MED-EKG) as part of the evaluation system. The TWR-MCF51MM-KIT operates as a standalone debug tool and can also be combined and used as part of the modular Tower System development platform
主要特色
-
Embedded System TypeMCU
-
Family NameColdFire
-
Core ProcessorColdfire V1
-
PlatformTower System
Featured Parts (43)
| 零件编号 | 供应商 | 类别 | 说明 | |||
|---|---|---|---|---|---|---|
|
SN74LVC1T45DRLRG4 | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 1-CH Bidirectional 6-Pin SOT-563 T/R | 买入 | |
|
SN74LVC1T45DCKT | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
|
SN74LVC1T45DCKR-P | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 1-CH Bidirectional 6-Pin SC-70 | 买入 | |
|
ICL3232IVZ | Renesas Electronics | Bus Line Transceivers | Dual Transmitter/Receiver RS-232 16-Pin TSSOP Tube | 买入 | |
|
|
SN74LVC1T45DCKRE4 | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
|
|
SN74LVC1T45DCKRG4 | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
|
LD1117AS12TR | STMicroelectronics | Linear Regulators | LDO Regulator Pos 1.2V 1.2A 4-Pin(3+Tab) SOT-223 T/R | 买入 | |
|
ICL3232IVZ-T7A | Renesas Electronics | Bus Line Transceivers | Dual Transmitter/Receiver RS-232 16-Pin TSSOP T/R | 买入 | |
|
|
V62/09608-01XE | Texas Instruments | Level Translators | Voltage Level Translator 1-CH Bidirectional 6-Pin SC-70 T/R | 买入 | |
|
SN74LVC1T45DBVRE4 | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 1-CH Bidirectional 6-Pin SOT-23 T/R | 买入 | |
|
|
LD1117AS18TR | STMicroelectronics | Linear Regulators | LDO Regulator Pos 1.8V 1A 4-Pin(3+Tab) SOT-223 T/R | 买入 | |
|
|
ICL3232IVZ-T | Renesas Electronics | Bus Line Transceivers | Dual Transmitter/Receiver RS-232 16-Pin TSSOP T/R | 买入 | |
