LM25056EVAL/NOPB, Evaluation Board using LM25056 for System Power Measurement IC With PMBus
使用 Texas Instruments 的 LM25056APSQ 的参考设计
1 / 2
依据最终产品
- Backplane Distributed Power
- Power Meter
- Servers
说明
- LM25056EVAL/NOPB, Evaluation Board provides the design engineer with a telemetry measurement IC board with a PMBUs compliant SMBus/I2C interface. This application note describes the various functions of the board, how to test and evaluate it, and how to use the companion graphical user interface (GUI). The GUI is used to collect telemetry, configure warning and fault thresholds, and assist the designer with selection of external components for a specific application
主要特色
-
Conversion TypeDC to DC
-
Input Voltage3 to 15 V
Featured Parts (4)
