BUF16821EVM-USB, Evaluation Board and Software Tutorial based on BUF16821 Programmable Gamma-Voltage Generator
使用 Texas Instruments 的 BUF16821 的参考设计
1 / 1
依据最终产品
- LCD TFT Display
说明
- BUF16821EVM-USB, Evaluation Board is a platform for evaluating the performance of the BUF16821 under various signal, reference, and supply conditions. The BUF16821 is a programmable gamma-voltage generator and VCOM calibrator with integrated two-bank memory. This device offers 16 programmable gamma channels and two programmable VCOM channels, making it ideal for 10-bit source TFT-LCD reference drivers
主要特色
-
Interface StandardsSPI|I2C
-
Supply VoltageSingle(6) V
-
Input Voltage9 to 20 V
-
FunctionsLine Transmitter/Receiver
Featured Parts (3)
| 零件编号 | 供应商 | 类别 | 说明 | |||
|---|---|---|---|---|---|---|
|
SN74LVC1G17DBVR | Texas Instruments | Buffers and Line Drivers | Schmitt Trigger Buffer 1-CH Non-Inverting Push-Pull CMOS 5-Pin SOT-23 T/R | 买入 | |
|
BUF16821AIPWPR | Texas Instruments | Amplifiers Misc | Programmable Gamma-Voltage Generator 28-Pin HTSSOP EP T/R | 买入 | |
|
|
BUF16821BIPWPR | Texas Instruments | Amplifiers Misc | Programmable Gamma-Voltage Generator 28-Pin HTSSOP EP T/R | 买入 | |
