TE Connectivity2226910-1圆形连接器

DESIGNED . . . AUTHORIZED . . . US ARMY NETT WARRIOR SOLDIER VEST APPLICATIONS.

Authorized for Use in Nett Warrior Soldier Vests and Peripheral Devices.

The Nett Warrior program was developed by the US Army to provide ground soldiers with instant situational awareness and communications capability by directly connecting them to the army’s tactical network. Like all communications devices, smaller and lighter is the order of the day. Every ounce saved is extra weight taken off the backs of our soldiers. TE Connectivity (TE) is now an authorized source for Nett Warrior soldier vest and vest peripheral devices. This now gives the industry another authorized source for Nett Warrior connectors.

Small circular push/pull and quick disconnect ruggedized connector designed for battlefield conditions. Developed to provide ground soldiers with instant situational awareness and communication capabilities.

Applications

• •  Soldier Vest Cables
• •  Battery Packs
• •  Antennas
• •  Communication/Power Hubs
• •  Radios
• •  Military Vehicles

Application images

Features & Benefits

• •  Small
• •  Light
• •  Tough
• •  Compatible
• •  High Performance
• •  Durable/Rugged

Specs

• •  Meets mechanical and environmental performance requirements of MIL-STD-810G
• •  Meets IP67 target when in the mated position
• •  Push/pull quick disconnect coupling meets breakaway force of 13 +/- 3 lbs.
• •  Offer OCH options with less breakaway force (2-3 lb. option & 6-8 lb. option)
• •  Standard OCH contacts rated to 5A
• •  Design in-process to meet up to 7.5/8-10A
