| RoHS (Unione Europea) | Compliant |
| ECCN (Stati Uniti) | EAR99 |
| Stato del componente | Active |
| Codice HTS | COMPONENTS |
| Automotive | No |
| PPAP | No |
| Categoria prodotti | Small Signal |
| Configuration | Single Quad Drain |
| Channel Mode | Enhancement |
| Channel Type | P |
| Number of Elements per Chip | 1 |
| Maximum Drain-Source Voltage (V) | 6 |
| Maximum Gate-Source Voltage (V) | -6 |
| Maximum Gate Threshold Voltage (V) | 1.2 |
| Maximum Continuous Drain Current (A) | 2 |
| Maximum Drain-Source Resistance (mOhm) | 84@4.5V |
| Maximum Power Dissipation (mW) | 270@Ta=85°C |
| Typical Fall Time (ns) | 20 |
| Typical Rise Time (ns) | 15 |
| Typical Turn-Off Delay Time (ns) | 60 |
| Typical Turn-On Delay Time (ns) | 15 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 150 |
| Packaging | Tape and Reel |
| Typical Drain-Source Resistance @ 25°C (mOhm) | 70@4.5V|76@3.6V|92@2.5V|125@1.8V |
| Mounting | Surface Mount |
| Package Height | 1(Max) mm |
| Package Width | 1.35(Max) mm |
| Package Length | 2.25(Max) mm |
| PCB changed | 6 |
| Standard Package Name | SOT |
| Supplier Package | SC-70 |
| Pin Count | 6 |
| Lead Shape | Gull-wing |
