| RoHS (Unione Europea) | Compliant |
| ECCN (Stati Uniti) | EAR99 |
| Stato del componente | Active |
| Codice HTS | 8541.41.00.00 |
| Automotive | No |
| PPAP | No |
| Type | Uni-Color |
| Categoria prodotti | Chip LED |
| Color | White |
| Lens Shape Type | Circular |
| Mounting Orientation | Top Mount |
| Luminous Flux | 310lm |
| Viewing Angle (°) | 120 |
| Maximum Forward Current (mA) | 1000 |
| Test Current (mA) | 1000 |
| Maximum Forward Voltage (V) | 3.5 |
| Minimum Forward Voltage (V) | 2.5 |
| Typical Forward Voltage (V) | 2.9 |
| Maximum Junction Temperature (°C) | 150 |
| Internal Protection | No |
| Maximum Case Temperature (°C) | 135 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 135 |
| Typical Color Temperature | 4100K |
| Lead Standoff | No |
| Minimum Color Temperature | 3500K |
| Maximum Color Temperature | 4100K(Typ) |
| Test Junction Temperature (°C) | 150(Max) |
| Temperature Coefficient of Voltage (mV/°C) | -2 to -4 |
| Supplier Color | Neutral White |
| Special Color | Neutral White |
| Color Rendering Index | 65 |
| High Power | Yes |
| High Brightness | Yes |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 1.9 |
| Package Width | 3.05 |
| Package Length | 4.49 |
| PCB changed | 2 |
| Supplier Package | SMD EP |
| Pin Count | 2 |
