HARTING14020814402000Blocchi terminali connettore
Conn Terminal Block 8 POS 3.5mm Solder RA Thru-Hole 12A har-flexicon® Bulk
| Compliant with Exemption | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| SVHC | Yes |
| Tasso di SVHC superiore ai limiti consentiti | Yes |
| Automotive | No |
| PPAP | No |
| Terminal Block | |
| 8 | |
| 3.5 | |
| 1 | |
| 8 | |
| Solder | |
| Right Angle | |
| 12 | |
| 300V | |
| 1000 | |
| -40 | |
| 110 | |
| Bulk | |
| 28 | |
| 7.3 | |
| 8.5 | |
| Black | |
| har-flexicon® | |
| Through Hole |
Know that you will have strong connections between circuits when you use Harting's 14020814402000 PCB terminal block. This is a 1-row connector. It has a maximum voltage rating of 300 V. It has a right angle body orientation. Its pitch is 3.5 mm. 14020814402000 is housed in polyamide/polyphthalamide. This device has a maximum current rating of 12 A. This quick disconnect terminal has an operating temperature of -40 to 110 °C. Its wire is 16-28 AWG. It uses the solder termination method. This product is 28 mm long, 8.5 mm tall and 7.3 mm deep.
| EDA / CAD Models |
