PHOENIX CONTACT1915259Embases de raccordement et réceptacles PCB
Conn Shrouded Header (4 Sides) HDR 6 POS 5.08mm Press Fit ST Thru-Hole
| Compliant | |
| EAR99 | |
| Obsolete | |
| 8536.69.40.40 | |
| Automotive | No |
| PPAP | No |
| Shrouded Header (4 Sides) | |
| HDR | |
| 6 | |
| 1 | |
| Press Fit | |
| 5.08 | |
| Straight | |
| 12 | |
| 320V | |
| 3.78 | |
| 40.64 | |
| 8.6 | |
| 12 | |
| Through Hole |
Make strong and binding connections on your circuit boards by adopting this shrouded 1915259 connector from Phoenix Contact. This HDR connector has 6 contacts that are plated with tin. It has a straight body orientation. It has a header type gender. Its pitch is 5.08 mm. It has a maximum voltage rating of 320 V. This is a 1-row connector. This device has a maximum current rating of 12 A. 1915259 is housed in green polybutylene terephthalate. It uses the press fit termination method. This product is 40.64 mm long, 12 mm tall and 8.6 mm deep.
