TPS23750EVM-107, TPS23750 Buck-Converter Evaluation Board - HPA107

Reference Design using part TPS23750PWP by Texas Instruments

Enlarge
Image 1 / 1

Manufacturer

Texas Instruments
  • Application Category
    Power Supplies
  • Product Type
    DC to DC Multi-Output Power Supplies
Buy

Associated Documents

For End Products

  • Power Over Ethernet

Description

  • TPS23750EVM-107, TPS23750 Buck-Converter Evaluation Board. The TPS23750EVM-107 evaluation module implements an IEEE 802.3af-compliant class-3 power interface and a non-isolated DC/DC switching converter using the TPS23750 powered device (PD) controller in a typical power-over-Ethernet (PoE) configuration

Key Features

  • Conversion Type
    DC to DC
  • Input Voltage
    0 to 57 V
  • Output Voltage
    3.3|5 V
  • Output Current
    2@5V|2.5@3.3V A
  • Efficiency
    80 %
  • Topology
    Buck

Featured Parts (3)

Featured Parts
Part Number Manufacturer Type Description
TPS23750PWPRG4 Texas Instruments Power Over Ethernet - PoE Controllers Power Over Ethernet PD Controller 0V 67V 20-Pin HTSSOP EP Buy
TPS23750PWPR Texas Instruments Power Over Ethernet - PoE Controllers Power Over Ethernet PD Controller 0V 67V 20-Pin HTSSOP EP Buy
TPS23750PWP Texas Instruments Power Over Ethernet - PoE Controllers Power Over Ethernet PD Controller 0V 67V 20-Pin HTSSOP EP Buy
