PMP2696, Non-Synchronous Buck Converter generating 3.3V input to an output of 13V@1A

Reference Design using part TPS54160DGQ by Texas Instruments

Enlarge
Image 1 / 1

Manufacturer

Texas Instruments
  • Application Category
    Power Supplies
  • Product Type
    DC to DC Single Output Power Supplies

Associated Documents

For End Products

  • GPS
  • Home Entertainment
  • Industrial Control
  • Video and Imaging

Description

  • PMP2696, Low cost non synchronous buck converter for high input voltage provides 3.3V at 1A with TPS54160

Key Features

  • Conversion Type
    DC to DC
  • Input Voltage
    3.3 V
  • Output Voltage
    13 V
  • Output Current
    1 A
  • Efficiency
    85 %
  • Topology
    Buck

Featured Parts (4)

Featured Parts
Part Number Manufacturer Type Description
TPS54160DGQR Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 3.5V to 60V Synchronous Step Down Single-Out 0.8V to 58V 1.5A 10-Pin HVSSOP EP T/R Buy
TPS54160DGQ Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 3.5V to 60V Synchronous Step Down Single-Out 0.8V to 58V 1.5A 10-Pin HVSSOP EP Tube Buy
TPS54160DGQG4 Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 3.5V to 60V Synchronous Step Down Single-Out 0.8V to 58V 1.5A 10-Pin HVSSOP EP Tube Buy
TPS54160DGQRG4 Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 3.5V to 60V Synchronous Step Down Single-Out 0.8V to 58V 1.5A 10-Pin HVSSOP EP T/R Buy
