AN-1666 LM2735X 6-Pin LLP Demo Board

Reference Design using part LM2735XSD by Texas Instruments

Enlarge
Image 1 / 1

Manufacturer

Texas Instruments
  • Application Category
    Power Supplies
  • Product Type
    DC to DC Single Output Power Supplies

Associated Documents

For End Products

  • Automotive and Transportation
  • Digital Still Camera (DSC)
  • LCD/OLED Display
  • LED Lighting
  • USB Dongle
  • Video Camera

Description

  • Demo Board included in this shipment converts 3V to 5.5V input to 12V output for up to 500mA load current using the LM2735X 1.6MHz DC-DC switching converter

Key Features

  • Conversion Type
    DC to DC
  • Input Voltage
    3 to 5.5 V
  • Output Voltage
    12 V
  • Output Current
    0.5 A
  • Efficiency
    89 %
  • Topology
    Boost

Featured Parts (5)

Featured Parts
Part Number Manufacturer Type Description
LM2735XSD/NOPB Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 2.7V to 5.5V Step Up Single-Out 3V to 24V 3A 6-Pin WSON EP T/R Buy
LM2735XSDX/NOPB Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 2.7V to 5.5V Step Up Single-Out 3V to 24V 3A 6-Pin WSON EP T/R Buy
LM2735XSD Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 2.7V to 5.5V Step Up Single-Out 3V to 24V 3A 6-Pin WSON EP T/R Buy
LM2735XSD/NOPB Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 2.7V to 5.5V Step Up Single-Out 3V to 24V 3A 6-Pin WSON EP T/R Buy
LM2735XSDX/NOPB Texas Instruments DC to DC Converter and Switching Regulator Chip Conv DC-DC 2.7V to 5.5V Step Up Single-Out 3V to 24V 3A 6-Pin WSON EP T/R Buy
