Diodes IncorporatedDMT3020LFDB-7MOSFETs

Diodes Incorporated’s DMT/DMTH MOSFETs Featuring Shielded-Gate Technology

Diodes Incorporated’s DMT/DMTH MOSFET family features state of the art shielded-gate technology that provides a multitude of benefits. This technology opens the door to a wide range of advantages including: higher N-doping, decreased Qgd that reduces charge coupling, improved Figure of Merit (FOM) that reduces switching and conduction losses, ultra-low Qg for fast turn-on/off speeds, and ultra-low Ron for high current density. All these features and more are housed in multiple package options, in support of a wide range of applications and design needs.

Applications:

• Industrial Automation
• Home Appliances
• Automotive (Electronic Hand Brakes, Pumps)
• eBikes / Drones/ Power Tools
• Garage Openers
• USB PDs
• USB Type-C
• Chargers
• Quick chargers
• White Goods (Fridges, etc.)
• Set-Top Boxes
• TVs,
• Power over Ethernet (PoE)



Features and Benefits:

• State of The Art Shielded-Gate Technology
• Low FOM nMOS
• Reduced RDS(on)
• Higher N-Doping
• Ultra-Low Ron for High Current Density
• Decreased Qgd That Reduces Charge Coupling
• Ultra-Low Qg for Fast Turn-On/Off Speeds
• Fast Switching Speed
• Rated to +150°C/+175°C – Ideal for High Ambient Temperature Environments (DMTH automotive parts)
• Increased BVDSS
• Wide Voltage Range Portfolio
• A Variety of Package Types to Support Different Market Requirements and Designs
• Totally Lead-Free & Fully RoHS Compliant
• Halogen and Antimony Free. “Green” Devices
• Suitable for automotive applications requiring specific change control (Select parts)
• AEC-Q101 qualified, PPAP capable, and manufactured in IATF 16949 certified facilities (Select parts)
• Please see individual datasheets for each part, for additional benefits and features.
