| 欧盟RoHS指令 | Compliant with Exemption |
| 美国出口管制分类ECCN编码 | EAR99 |
| 环保无铅 | Obsolete |
| 美国海关商品代码 | 8517.62.00.90 |
| Automotive | No |
| PPAP | No |
| Type | TX/RX |
| Emitter Type | VCSEL Laser |
| Fiber Mode | Multi Mode |
| Connector Type | LC |
| Maximum Data Rate | 10.52Gbps |
| Peak Wavelength (nm) | 850 |
| Form Factor | SFP+ |
| Rise Time (ns) | 0.028(Min) |
| Maximum Fall Time (ns) | 0.028(Min) |
| Average Optical Output Power (dBm) | -7.3(Min) |
| Minimum Operating Supply Voltage (V) | 3.14 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Maximum Operating Supply Voltage (V) | 3.47 |
| Minimum Operating Temperature (°C) | -5 |
| Maximum Operating Temperature (°C) | 85 |
| Supplier Temperature Grade | Commercial |
| Mounting | Snap Fit To Panel |
| Package Height | 11.67 mm |
| Package Width | 13.7 mm |
| Package Length | 56.5 mm |
