| 欧盟RoHS指令 | Compliant with Exemption |
| 美国出口管制分类ECCN编码 | EAR99 |
| 环保无铅 | Active |
| 美国海关商品代码 | 8541.10.00.80 |
| SVHC | Yes |
| Automotive | Yes |
| PPAP | Unknown |
| 产品类别 | Power MOSFET |
| Material | SiC |
| Configuration | Hex |
| Channel Mode | Enhancement |
| Channel Type | N |
| Number of Elements per Chip | 6 |
| Maximum Drain-Source Voltage (V) | 1200 |
| Maximum Gate-Source Voltage (V) | 23 |
| Operating Junction Temperature (°C) | -40 to 175 |
| Maximum Continuous Drain Current (A) | 700(Typ) |
| Maximum Drain-Source Resistance (mOhm) | 2.8@15V |
| Typical Gate Charge @ Vgs (nC) | 1696@15V |
| Typical Input Capacitance @ Vds (pF) | 51300@800V |
| Maximum Power Dissipation (mW) | 1852000(Typ) |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Supplier Temperature Grade | Automotive |
| Mounting | Screw |
| Package Height | 32 mm |
| Package Width | 92 mm |
| Package Length | 154.5 mm |
| PCB changed | 39 |
| Supplier Package | Case YM |
| Pin Count | 39 |
