PHOENIX CONTACT1825459Connector Terminal Blocks
Conn Terminal Block M 16 POS 5.08mm Screw RA Cable Mount 12A Cardboard
| Compliant | |
| EAR99 | |
| Active | |
| 8536.90.40.00 | |
| Automotive | No |
| PPAP | No |
| Terminal Block | |
| M | |
| 16 | |
| 5.08 | |
| 1 | |
| 16 | |
| Screw | |
| Right Angle | |
| 12 | |
| 320V | |
| -40 | |
| 105 | |
| Cardboard | |
| 27.137 | |
| 91.4 | |
| 19.2 | |
| 15 | |
| Green | |
| Cable Mount |
This 1825459 PCB terminal block manufactured from Phoenix Contact will bridge different sections of wires together. This M connector has 16 contacts that are plated with tin. It has a maximum voltage rating of 320 V. Its pitch is 5.08 mm. It has a right angle body orientation. It has a male type gender. This is a 1-row connector. This device has a maximum current rating of 12 A. 1825459 is housed in polyamide. It uses the screw termination method. This product is 91.4 mm long, 15 mm tall and 19.2 mm deep. Its wire is 12-24 AWG.
| EDA / CAD Models |
