SamtecTSW-115-05-G-TCabezales del conector y receptáculos PCB

This unshrouded TSW-115-05-G-T header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector's 45 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 3-row connector. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 38.1 mm long, 5.21 mm tall and 7.62 mm deep. TSW-115-05-G-T is housed in black polyester.
