SamtecTSW-140-07-L-D连接器插头及 PCB 插座

This unshrouded TSW-140-07-L-D header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector's 80 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a straight body orientation. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. It uses the solder termination method. This product is 101.6 mm long, 8.38 mm tall and 5.08 mm deep. TSW-140-07-L-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.
