| 欧盟RoHS指令 | Compliant |
| 环保无铅 | Active |
| 美国海关商品代码 | 8517.62.00.90 |
| Automotive | Unknown |
| PPAP | Unknown |
| Type | TX/RX |
| Emitter Type | FP/PIN |
| Connector Type | SC |
| Maximum Data Rate | 155Mbps |
| Peak Wavelength (nm) | 1310/1610(Max) |
| Form Factor | 1x9 |
| Rise Time (ns) | 2 |
| Maximum Fall Time (ns) | 2 |
| Average Optical Output Power (dBm) | -15 to -8 |
| Maximum Output Current (mA) | 30 |
| Minimum Operating Supply Voltage (V) | 4.75 |
| Typical Operating Supply Voltage (V) | 5 |
| Maximum Operating Supply Voltage (V) | 5.25 |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 70 |
| Packaging | ESD |
| Mounting | Through Hole |
| Package Height | 9.8 |
| Package Width | 25.4 |
| Package Length | 39.6 |
| PCB changed | 11 |
| Pin Count | 11 |
