PHOENIX CONTACT1861730连接器插头及 PCB 插座
Conn Wire to Board HDR 3 POS 3.81mm Solder RA Thru-Hole
| Compliant | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| Automotive | No |
| PPAP | No |
| Wire to Board | |
| HDR | |
| 3 | |
| 1 | |
| Solder | |
| 3.81 | |
| Right Angle | |
| 8 | |
| 160V | |
| -40 | |
| 100 | |
| 1.52 | |
| 7.25 | |
| 25 | |
| 12.82 | |
| Through Hole |
Use this wire to board 1861730 header connector from Phoenix Contact where IDC ribbon cables are used. This HDR connector has 3 contacts that are plated with tin. It has a right angle body orientation. This is a 1-row connector. Its pitch is 3.81 mm. It has a header type gender. It has a maximum voltage rating of 160 V. This device has a maximum current rating of 8 A. This product is 7.25 mm long, 12.82 mm tall and 25 mm deep. 1861730 is housed in green polybutylene terephthalate. It uses the solder termination method.
