Amphenol Communications Solutions68602-104HLFConnector Headers and PCB Receptacles



Use this unshrouded 68602-104HLF connector from FCI when board-to-board interconnects is required. This HDR connector's 4 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. This is a 2-row connector. Its pitch is 2.54 mm. It has a straight body orientation. It has a header type gender. It has a maximum voltage rating of 1500 VAC. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This connector has an operating temperature of -65 to 125 °C. This product is 5.08 mm long, 8.38 mm tall and 4.83 mm deep. 68602-104HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer.
