| RoHS (Unión Europea) | Compliant with Exemption |
| ECCN (Estados Unidos) | EAR99 |
| Estatus de pieza | Active |
| Código HTS | 8541.30.00.80 |
| SVHC | Yes |
| Índice de SEP por encima del límite autorizado | Yes |
| Automotive | No |
| PPAP | No |
| Maximum Rate of Rise of On-State Current (A/us) | 120(Typ) |
| Surge Current Rating (A) | 4 |
| Maximum Holding Current (mA) | 100 |
| Repetitive Peak Reverse Voltage (V) | 180 |
| Peak On-State Voltage (V) | 1.5@1A |
| Repetitive Peak Forward Blocking Voltage (V) | 180 |
| Maximum Breakover Voltage (V) | 250 |
| Repetitive Peak Off-State Current (mA) | 0.005 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Diameter | 2.7(Max) mm |
| Mounting | Through Hole |
| Package Length | 5.2(Max) mm |
| PCB changed | 2 |
| Standard Package Name | DO |
| Supplier Package | DO-41 |
| Pin Count | 2 |
| Lead Shape | Through Hole |
