| RoHS (Unión Europea) | Compliant |
| ECCN (Estados Unidos) | EAR99 |
| Estatus de pieza | Active |
| Código HTS | 8541.41.00.00 |
| Automotive | No |
| PPAP | No |
| Type | Uni-Color |
| Categoría del producto | Chip LED |
| Color | White |
| Number of LEDs | 1 |
| LED Material | InGaN |
| Lens Shape Type | Rectangular |
| Lens Appearance | Milky White |
| Mounting Orientation | Right Angle |
| Intensity | 2200mcd |
| Maximum Forward Current (mA) | 30 |
| Test Current (mA) | 20 |
| Maximum Forward Voltage (V) | 3.2(Typ) |
| Reverse Voltage (V) | 5 |
| Typical Forward Voltage (V) | 3.2 |
| Internal Protection | No |
| Maximum Power Dissipation (mW) | 117 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Typical Color Temperature | x=0.3/y=0.28 |
| Lead Standoff | No |
| Supplier Color | White |
| Special Color | White |
| High Power | No |
| High Brightness | Yes |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 0.8 mm |
| Package Width | 1.2 mm |
| Package Length | 2.45 mm |
| PCB changed | 2 |
| Supplier Package | Case 2812 |
| Pin Count | 2 |
| Lead Shape | J-Lead |
