| RoHS (Unión Europea) | Compliant |
| ECCN (Estados Unidos) | EAR99 |
| Estatus de pieza | Active |
| Código HTS | 8541.29.00.95 |
| Automotive | No |
| PPAP | No |
| Categoría del producto | Power MOSFET |
| Configuration | Dual Common Drain |
| Channel Mode | Enhancement |
| Channel Type | N |
| Number of Elements per Chip | 2 |
| Maximum Gate-Source Voltage (V) | ±20 |
| Typical Gate Charge @ Vgs (nC) | 15@4.5V|31@10V |
| Typical Input Capacitance @ Vds (pF) | 1620@15V |
| Maximum Power Dissipation (mW) | 2500 |
| Typical Fall Time (ns) | 712 |
| Typical Rise Time (ns) | 260 |
| Typical Turn-Off Delay Time (ns) | 709 |
| Typical Turn-On Delay Time (ns) | 164 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Operating Temperature (°C) | 150 |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 0.2 |
| Package Width | 1.52(Max) |
| Package Length | 3.42(Max) |
| PCB changed | 10 |
| Supplier Package | PicoStar |
| Pin Count | 10 |
