| RoHS (Unión Europea) | Compliant |
| ECCN (Estados Unidos) | EAR99 |
| Estatus de pieza | Unconfirmed |
| Código HTS | 8542.39.00.90 |
| Automotive | No |
| PPAP | No |
| Type | Analog Switch |
| Configuration | Octal SPST |
| Switch Architecture | SPST |
| Number of Channels per Chip | 8 |
| Number of Inputs per Chip | 8 |
| Number of Outputs per Chip | 8 |
| Chip Enable Signals | Yes |
| Polarity | Non-Inverting |
| Maximum Turn-On Time (ns) | 5000 |
| Maximum Turn-Off Time (ns) | 5000 |
| Input Signal Type | Single |
| Output Signal Type | Single |
| Minimum Dual Supply Voltage (V) | ±40 |
| Maximum Dual Supply Voltage (V) | -160|200 |
| Maximum Supply Current (mA) | 7@40V@-7V@-160V |
| Maximum On Resistance (Ohm) | 38@40V@-160V |
| Maximum On Resistance Range (Ohm) | 35 to 45 |
| Power Supply Type | Dual |
| Maximum Power Dissipation (mW) | 2300 |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 70 |
| Packaging | Tray |
| Mounting | Surface Mount |
| Package Height | 1.4 mm |
| Package Width | 7 mm |
| Package Length | 7 mm |
| PCB changed | 48 |
| Standard Package Name | QFP |
| Supplier Package | LQFP |
| Pin Count | 48 |
| Lead Shape | Gull-wing |
