PHOENIX CONTACT1859535Cabezales del conector y receptáculos PCB
Conn Shrouded Header (4 Sides) HDR 4 POS 5.08mm Press Fit ST Thru-Hole Cardboard
| Compliant | |
| EAR99 | |
| Obsolete | |
| 8536.69.40.40 | |
| Automotive | No |
| PPAP | No |
| Shrouded Header (4 Sides) | |
| HDR | |
| 4 | |
| 1 | |
| Press Fit | |
| 5.08 | |
| Straight | |
| 12 | |
| 320V | |
| 1000000 | |
| 1.5 | |
| -40 | |
| 100 | |
| 100 | |
| Cardboard | |
| 1.803 | |
| 22.32 | |
| 8.6 | |
| 12 | |
| Through Hole |
Phoenix Contact's shrouded 1859535 header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This HDR connector has 4 contacts that are plated with tin. It has a maximum voltage rating of 320 V. Its pitch is 5.08 mm. It has a straight body orientation. It has a header type gender. This is a 1-row connector. This device has a maximum current rating of 12 A. 1859535 is housed in green polybutylene terephthalate. It uses the press fit termination method. This product is 22.32 mm long, 12 mm tall and 8.6 mm deep.
