Molex0533071271Cabezales del conector y receptáculos PCB

This board to board 0533071271 header connector from Molex is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector's 12 contacts that are made out of phosphor bronze and plated with tin over nickel. Its pitch is 0.8 mm. This is a 2-row connector. It has a straight body orientation. It has a maximum voltage rating of 50 V. It has a header type gender. This device has a maximum current rating of 0.5 A/contact. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It uses the solder termination method. 0533071271 is housed in natural polyphenylene sulfide. This connector has an operating temperature of -20 to 105 °C. This product is 6.6 mm long, 3.65 mm tall and 5.1 mm deep.
