SamtecTSW-203-07-L-SConnector Headers and PCB Receptacles

Reduce safety concerns with this unshrouded TSW-203-07-L-S header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector's 3 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 5.08 mm. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. It has a header type gender. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 12.7 mm long, 8.38 mm tall and 2.54 mm deep. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. TSW-203-07-L-S is housed in black polyester.
