| EU RoHS | Not Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.90 |
| Automotive | No |
| PPAP | No |
| Number of Channels per Chip | 2 |
| Transmit FIFO (byte) | 16 |
| Receive FIFO (byte) | 16 |
| Maximum Data Rate | 1MBd |
| Transmitter and Receiver FIFO Counter | No |
| Minimum Operating Supply Voltage (V) | 4.75 |
| Maximum Operating Supply Voltage (V) | 5.25 |
| Typical Operating Supply Voltage (V) | 5 |
| Maximum Supply Current (mA) | 50 |
| Maximum Power Dissipation (mW) | 1689 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Operating Temperature (°C) | 125 |
| DMA Support | Yes |
| False Start Bit Detection | No |
| Automatic Software Flow Control | No |
| Supplier Temperature Grade | Military |
| Automatic Hardware Flow Control | Yes |
| Packaging | Tube |
| Mounting | Surface Mount |
| Package Height | 3.56 |
| Package Width | 12.51 |
| Package Length | 12.51 |
| PCB changed | 68 |
| Standard Package Name | FPAK |
| Supplier Package | CFPAK |
| Pin Count | 68 |
| Lead Shape | Flat |
