| EU RoHS | Compliant with Exemption |
| ECCN (US) | 5A002a.1. |
| Part Status | Active |
| HTS | COMPONENTS |
| Automotive | Unknown |
| PPAP | Unknown |
| Module/IC Classification | Module |
| Modulation Technique | OQPSK |
| Solutions | ISM |
| Flash Size (KB) | 128 |
| Number of Channels | 15 |
| External Antenna Connector Type | U.FL |
| Maximum Data Rate (Kbps) | 2000 |
| Maximum Operating Frequency (MHz) | 2400(Typ) |
| ISM Band | 2.4GHz |
| Typical Sensitivity | -103dBm |
| Protocol Stack | Snap |
| Interface | GPIO/UART |
| Maximum Output Power | 20dBm |
| Minimum Operating Supply Voltage (V) | 2 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Outdoor Range | 3mi |
| Processing Unit Type | Microcontroller |
| Antenna Mounting | External |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Mounting | Surface Mount |
| Package Height | 3.27 |
| Package Width | 19 |
| Package Length | 29.8 |
| PCB changed | 64 |
| Supplier Package | SMD Module |
| Pin Count | 64 |
