| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8542.39.00.90 |
| Automotive | No |
| PPAP | No |
| Driver Type | High Side|Low Side |
| Bridge Type | Half Bridge |
| Number of Drivers | 2 |
| High and Low Sides Dependency | Dependent |
| Type | GaNFET |
| Number of Outputs | 2 |
| Maximum Operating Frequency (kHz) | 10000 |
| Maximum Propagation Delay Time (ns) | 50 |
| Input Logic Compatibility | TTL |
| Minimum Operating Supply Voltage (V) | 4.75 |
| Typical Operating Supply Voltage (V) | 5 |
| Maximum Operating Supply Voltage (V) | 5.25 |
| Maximum Supply Current (mA) | 5 |
| Typical Input Low Threshold Voltage (V) | 1.66 |
| Typical Input High Threshold Voltage (V) | 2.06 |
| Output Resistance (Ohm) | 0.015 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 125 |
| Special Features | Under Voltage Lockout |
| Maximum Turn-On Delay Time (ns) | 8 |
| Maximum Turn-Off Delay Time (ns) | 8 |
| Latch-Up Proof | No |
| Packaging | Tape and Reel |
| Mounting | Surface Mount |
| Package Height | 2(Max) mm |
| Package Width | 6.1(Max) mm |
| Package Length | 8.1(Max) mm |
| PCB changed | 9 |
| Supplier Package | QFM |
| Pin Count | 9 |
| Lead Shape | No Lead |
