LED Power Supplies

IDLC-45-700

AC/DC LED Power Supply 44.8W Single 8-Pin

MEAN WELL

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Obsolete

• HTS

  8504.40.95.10

• Automotive

  No

• PPAP

  No

• Type

  Constant Current

• Input/Output Type

  AC/DC

• Number of Outputs

  1

• Output Voltage Range (VDC)

  38 to 64

• Maximum Output Current (mA)

  700

• Output Power (W)

  44.8

• Input Voltage Range

  90VAC to 295VAC|127VDC to 417VDC

• Dimming

  0-10V/PWM

• Power Factor Correction

  0.95(Min)

• Efficiency (%)

  85(Typ)

• Warranty

  3Year

• Minimum Operating Temperature (°C)

  -20

• Maximum Operating Temperature (°C)

  85

• Product Weight (g)

  220

• Mounting

  Screw

• Package Height

  25

• Package Width

  75

• Package Length

  120

• PCB changed

  8

• Pin Count

  8

• Lead Shape

  Lead Wire
