| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8517.62.00.90 |
| Automotive | Unknown |
| PPAP | Unknown |
| Type | TX/RX |
| Emitter Type | VCSEL Laser |
| Fiber Mode | Multi Mode |
| Connector Type | LC |
| Maximum Data Rate | 2.125Gbps(Typ) |
| Peak Wavelength (nm) | 860(Max) |
| Form Factor | SFF |
| Rise Time (ns) | 0.15/0.17 |
| Maximum Fall Time (ns) | 0.15/0.17 |
| Jitter (ns) | 0.119(Max)/0.123(Max) |
| Average Optical Output Power (dBm) | -9 to -2.5 |
| Maximum Forward Current (mA) | 240 |
| Minimum Operating Supply Voltage (V) | 3 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Maximum Power Dissipation (mW) | 750 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Supplier Temperature Grade | Industrial |
| Mounting | Through Hole |
| Package Height | 9.56 |
| Package Width | 13.46 |
| Package Length | 49.3 |
| PCB changed | 10 |
| Pin Count | 10 |
