| EU RoHS | Compliant with Exemption |
| ECCN (US) | 5A991.b.5.a |
| Part Status | Active |
| HTS | 8517.62.00.90 |
| SVHC | Yes |
| Automotive | Unknown |
| PPAP | Unknown |
| Type | TX/RX |
| Emitter Type | DFB Laser |
| Fiber Mode | Single |
| Connector Type | LC |
| Maximum Data Rate | 8.5Gbps |
| Peak Wavelength (nm) | 1345(Max)/1360(Max) |
| Form Factor | SFP+ |
| Rise Time (ns) | 0.12/0.06/0.09 |
| Maximum Fall Time (ns) | 0.12/0.06/0.09 |
| Jitter (ns) | 0.1224 |
| Maximum Forward Current (mA) | 300 |
| Minimum Operating Supply Voltage (V) | 3 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Minimum Operating Temperature (°C) | -5 |
| Maximum Operating Temperature (°C) | 85 |
| Supplier Temperature Grade | Extended |
| Mounting | Snap Fit To Panel |
| Package Height | 11.85 mm |
| Package Width | 14.8 mm |
| Package Length | 56.5 mm |
| PCB changed | 20 |
| Pin Count | 20 |
