3M8510-4500PLConnector Headers and PCB Receptacles

Wire to Board core range interconnect products: the proven 3M™ classics

3M™ offers the basic I/O Interconnect components for electronics design in general up to demanding applications.

In a wide range of applications - regardless of whether in device, machine and plant engineering, in automation, measurement or medical technology - these components are required as interfaces everywhere.

Use this socket strip 8510-4500PL connector from 3M when board-to-board interconnects is required. This SKT connector's 10 contacts that are made out of copper alloy and plated with gold over nickel. It has a straight body orientation. It has a socket type gender. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 1 A. 8510-4500PL is housed in gray glass filled polybutylene terephthalate. It uses the solder termination method. This product is 17.3 mm long, 10.8 mm tall and 7.1 mm deep. This connector has an operating temperature of -55 to 105 °C.
