| EU RoHS | Compliant |
| Part Status | Active |
| HTS | 8517.62.00.90 |
| Automotive | Unknown |
| PPAP | Unknown |
| Technology | IEEE 802.11b/g/n |
| Style | Module |
| Modulation Technique | DQPSK|DSSS|OFDM|QPSK|16QAM|64QAM|BPSK|CCK|DBPSK |
| Solutions | ISM |
| Covered Range (m) | 180 |
| Maximum Data Rate (Kbps) | 150000 |
| Band Mode | Single |
| Maximum Operating Frequency (MHz) | 2400(Typ) |
| ISM Band | 2.4GHz |
| Typical Sensitivity | -80dBm@11Mbps|-70dBm@54Mbps|-64dBm@130Mbps |
| Interface | USB |
| Maximum Output Power | 17dBm(Typ) |
| Maximum Current Consumption (TX) (mA) | 125 |
| Maximum Current Consumption (RX) (mA) | 68 |
| Antenna Mounting | On Board |
| Wi-Fi Compliant | Yes |
| Wi-Fi Direct | No |
| Security | 64bit WEP/128bit WEP/AES/TKIP/WPA/WPA2 |
| Operation Mode | Ad-Hoc|Infrastructure |
| Minimum Operating Temperature (°C) | -10 |
| Maximum Operating Temperature (°C) | 60 |
| Packaging | Retail |
| Package Height | 8 mm |
| Package Width | 15 mm |
| Package Length | 17 mm |
