PHOENIX CONTACT1803293Connector Headers and PCB Receptacles
Conn Wire to Board HDR 4 POS 3.81mm Solder RA Side Entry Thru-Hole Cardboard
| Compliant | |
| EAR99 | |
| Active | |
| COMPONENTS | |
| Automotive | No |
| PPAP | No |
| Wire to Board | |
| HDR | |
| 4 | |
| 1 | |
| Solder | |
| 3.81 | |
| Right Angle | |
| 8 | |
| 160V | |
| 5 | |
| 1.5 | |
| -40 | |
| 100 | |
| 25 | |
| Cardboard | |
| 1.06 | |
| 16.63 | |
| 9.2 | |
| 7.25 | |
| Contact Plating Thickness | ((3-5)/(1-3))um |
| 3.4 | |
| Through Hole |
Thanks to Phoenix Contact's shrouded 1803293 header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This HDR connector has 4 contacts that are plated with tin. It has a right angle body orientation. It has a maximum voltage rating of 160 V@IEC|300V@UL. This is a 1-row connector. Its pitch is 3.81 mm. It has a header type gender. This device has a maximum current rating of 8 A. This product is 16.63 mm long, 7.25 mm tall and 9.2 mm deep. 1803293 is housed in green polybutylene terephthalate. It uses the solder termination method.
