CONEC Elektronische Bauelemente GmbH163A13749XConnector D-Subminiature
Conn D-Sub PIN 25 POS Solder ST Thru-Hole 25 Terminal 1 Port
| Compliant | |
| EAR99 | |
| Active | |
| 8536.69.40.51 | |
| Automotive | No |
| PPAP | No |
| D-Sub | |
| PL | |
| 25 | |
| 25 | |
| 1 | |
| 2 | |
| Solder | |
| Straight | |
| PIN | |
| 7.5 | |
| 125V | |
| 5000 | |
| 10 | |
| -55 | |
| 125 | |
| 50 | |
| Steel | |
| Tin | |
| B | |
| No | |
| 53.42 | |
| 12.93 | |
| Gold Over Nickel | |
| Copper Alloy | |
| Through Hole |
Using the 163A13749X DVI connector from Conec is fast and easy for communicating between serial connections in your circuit. This 2-row connector has a single port. It has a maximum voltage rating of 125 V. It has a straight body orientation. 163A13749X is housed in polyester. This device has a maximum current rating of 7.5 A. This DVI connector has an operating temperature of -55 to 125 °C. This product is 53.42 mm long and 12.93 mm. Its 25 terminals use the solder termination method.
