HARTING Technology Group09562527612Connector D-Subminiature
Conn D-Sub F 26 POS 1.14mm Solder RA Thru-Hole 26 Terminal 1 Port
| Compliant with Exemption | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| SVHC | Yes |
| SVHC Exceeds Threshold | Yes |
| Automotive | No |
| PPAP | No |
| D-Sub | |
| RCP | |
| 26 | |
| 26 | |
| 1 | |
| 3 | |
| Solder | |
| 1.14 | |
| Right Angle | |
| F | |
| 2 | |
| 5000 | |
| 25 | |
| -40 | |
| 85 | |
| 50 | |
| Steel | |
| Nickel | |
| A | |
| No | |
| 39.5 | |
| 12.93 | |
| Noble Metal Over Nickel | |
| Copper Alloy | |
| Through Hole |
The high density d-sub 09562527612 DVI connector from Harting is perfect for communication between serial connections in your system. This female connector has 26 female contacts. This 3-row connector has a single port. It has a right angle body orientation. Its pitch is 2.29 mm. 09562527612 is housed in polybutylene terephthalate. Its 26 terminals use the solder termination method. This product is 12.93 mm tall.
