Molex0526101033Connector FFC-FPC
Conn FFC/FPC Connector SKT 10 POS 1mm Solder ST SMD Easy-On™ T/R
Other Part Names : 526101033
| Compliant | |
| EAR99 | |
| Obsolete | |
| COMPONENTS | |
| Automotive | No |
| PPAP | No |
| FFC/FPC Connector | |
| 10 | |
| 1 | |
| Solder | |
| 1 | |
| Straight | |
| SKT | |
| 1/Contact | |
| 125V | |
| 100 | |
| 20 | |
| -40 | |
| 85 | |
| Zero | |
| 30 | |
| Tape and Reel | |
| 0.533 | |
| 16.6 | |
| 4.5 | |
| 5.75 | |
| Easy-On™ | |
| Surface Mount |
Optimize the design of a space-limited electronic device with this ffc/fpc connector 0526101033 flexible printed circuit from Molex. It has a maximum voltage rating of 125 V. Its pitch is 1 mm. This socket type connector's 10 contacts that are made out of phosphor bronze and plated with tin silver bismuth over nickel. This is a 1-row connector. It has a straight body orientation. This device has a maximum current rating of 1 A/contact. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This product is 16.6 mm long, 5.75 mm tall and 4.5 mm deep. 0526101033 is housed in white polyamide. It uses the solder termination method. This flexible flat cable has an operating temperature of -40 to 85 °C.
