| EU RoHS | Supplier Unconfirmed |
| Part Status | Obsolete |
| HTS | 8517.62.00.90 |
| Automotive | Unknown |
| PPAP | Unknown |
| Technology | IEEE 802.11b/g/n |
| Style | Module |
| Modulation Technique | 16QAM|64QAM|BPSK|QPSK |
| Solutions | ISM |
| Maximum Data Rate (Kbps) | 300000 |
| Band Mode | Single |
| Minimum Operating Frequency (MHz) | 2312 |
| Maximum Operating Frequency (MHz) | 2484 |
| ISM Band | 2.4GHz |
| Typical Sensitivity | -80dBm@11Mbps|-70dBm@54Mbps|-64dBm@300Mbps |
| Interface | USB |
| Maximum Output Power | 17dBm |
| Maximum Current Consumption (TX) (mA) | 380 |
| Maximum Current Consumption (RX) (mA) | 250 |
| Wi-Fi Compliant | Yes |
| Wi-Fi Direct | No |
| Security | 64bit WEP/128bit WEP/AES/TKIP/WPA/WPA2/WPS |
| Operation Mode | Ad-Hoc|Infrastructure |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 50 |
| Packaging | Retail |
| Mounting | Socket |
| Package Height | 9.9 |
| Package Width | 24.4 |
| Package Length | 52.3 |
