| RoHS (Unión Europea) | Compliant |
| Estatus de pieza | Active |
| Código HTS | 8471.50.01.50 |
| Automotive | Unknown |
| PPAP | Unknown |
| Processor Type | Intel |
| Processor Family | Pentium |
| Processor Number | N4200 |
| Processor Cores | Quad Core |
| Processor Speed (Hz) | 1.5G |
| Processor Thermal Design Power (W) | 6 |
| Intel Technologies | Secure Boot/Intel VT-x/Intel VT-d/Intel EPT/Intel 64/Instruction Set/Idle States/Enhanced Intel SpeedStep/Thermal Monitoring/Intel HD Audio/Intel IPT |
| Form Factor | SMARC |
| Chipset Type | Integrated in SoC |
| JTAG Support | No |
| Data Cache Size (B) | 2M |
| BIOS | AMI Aptio UEFI 8MB |
| RAM Type | LPDDR4 |
| System Memory Maximum Size (B) | 8G |
| System Memory Speed | 2133MHz |
| UART | 4 |
| USART | 0 |
| SPI | 2 |
| I2C | 2 |
| CAN | 1 |
| USB | 6 |
| VGA | 0 |
| SATA | 1 |
| PATA | 0 |
| GPIO | 0 |
| Audio Interfaces | 0 |
| Video In | No |
| RS485 | 0 |
| RS232 | 0 |
| RS422 | 0 |
| PCI | 0 |
| AGP | 0 |
| Ethernet Controller Type | Intel I210 |
| Ethernet | 2 |
| Ethernet Speed | 1000Mbps |
| Display Type | LCD |
| Display Chipset Type | Intel Gen 9 HD |
| Display Interface | DP|eDP|HDMI|LVDS|MIPI-CSI |
| Graphic Card Resolution (Pixels) | 1920x1200@LVDS|3840x2160@HDMI|4096x2160@DP |
| Operating Systems | Linux|Linux Yocto|Win 10|Win 10 IoT Core|Win 10 IoT Enterprise |
| Android | Android 6.0 |
| Linux | Linux |
| Windows | Win 10|Win IoT Core |
| Medical Application | No |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Supplier Temperature Grade | Industrial |
