AC to DC Power Supplies

VMS-200C-15

AC/DC Power Supply Single-OUT 15V 13.3A 200W 11-Pin Tray

CUI Inc

Product Technical Specifications

• EU RoHS

  Compliant with Exemption

• ECCN (US)

  EAR99

• Part Status

  NRND

• HTS

  8504.40.95.30

• Automotive

  No

• PPAP

  No

• Type

  Regulated

• Style

  Open Frame

• Input/Output Type

  AC/DC

• Number of Outputs

  1

• Output Type

  Fixed

• Output Voltage (V)

  15

• Output Current (A)

  13.3

• Output Power (W)

  200

• Minimum AC Input Voltage (V)

  85

• Maximum AC Input Voltage (V)

  264

• Minimum DC Input Voltage (V)

  120

• Maximum DC Input Voltage (V)

  370

• Minimum Isolation Voltage

  4000VAC

• Line Regulation

  0.5%(Typ)

• Load Regulation

  0.5%(Typ)

• Maximum Input Current (A)

  3

• Input Frequency (Hz)

  47 to 63

• Tolerance (%)

  ±1(Typ)

• Efficiency (%)

  93(Typ)

• Configurable

  No

• Input Connector Type

  JST RCY Male

• Output Connector Type

  JST RCY Male

• Power Indicator

  Yes

• Ripple and Noise

  100mV(Max)

• Medical

  No

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  70

• Packaging

  Tray

• Product Weight (g)

  175

• Mounting

  Screw

• Package Height

  25.4 mm

• Package Width

  50.8 mm

• Package Length

  101.6 mm

• PCB changed

  11

• Pin Count

  11
