DC to DC Converter and Switching Regulator Module

THN 15-2425WIR

Module DC-DC 24VIN 2-OUT 24V/-24V 0.315A/0.315A 15W 6-Pin

Traco Power

Product Technical Specifications

• EU RoHS

  Compliant with Exemption

• ECCN (US)

  EAR99

• Part Status

  Active

• SVHC

  Yes

• SVHC Exceeds Threshold

  Yes

• Automotive

  Unknown

• PPAP

  Unknown

• Type

  Step Down

• Number of Outputs

  2

• Isolation

  Isolated

• Minimum Input Voltage (V)

  9

• Typical Input Voltage (V)

  24

• Maximum Input Voltage (V)

  36

• Output Voltage (V)

  -24, 24

• Output Current (A)

  0.315

• Output Power (W)

  15

• Minimum Isolation Voltage

  3000VDC

• Input/Output Type

  DC/DC

• Maximum Switching Frequency (kHz)

  300(Typ)

• Switching Regulator

  Yes

• Load Regulation

  1%

• Line Regulation

  0.5%

• Efficiency (%)

  91(Typ)

• On/Off Logic

  Positive

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  90

• Product Weight (g)

  16.5

• Output Type

  Fixed

• Mounting

  Through Hole

• Package Height

  9.9

• Package Width

  25.4

• Package Length

  25.4

• PCB changed

  6

• Pin Count

  6
